LPJ0011FBNL 100Base-T RJ45 Connector with Magnetic For I/O Date

Product Categories

LINK-PP INT'L TECHNOLOGY CO., LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: LPJ0011FBNL 100BaseT RJ45 Connector with Magnetic For IO Date
Brand: LINK-PP
Price: 1 USD

Place of Origin : China

Brand Name : LINK-PP

Certification : UL,ROHS,Reach,ISO

Model Number : LPJ0011FBNL

MOQ : 50/500/1000

Price : Supportive&Discounted

Packaging Details : 50PCS/tray;1200PCS/carton

Delivery Time : Stock

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3000K/month

Part Number : LPJ0011FBNL

Type : Magnetic RJ45 Jack

Speed : 10/100 Base-T

Indicator : With LEDs

Mounting Type : THT

Free Samples : Available

Contact Now

NOTES:
1. Designed to support applications, such as SOHO(ADSL modems), LAN-on Motherboard(LOM),hub and Switches.
2. Meets IEEE 802.3 specification
3. Connector Materials:
Housing: Thermoplastic PBT+30%G.F UL94V-0
Contact: Phosphor Bronze C5210R-EH Thickness=0.35mm
Pins: Brass C2680R-H Thickness=0.35mm
Shield: SUS 201-1/2H Thickness=0.2mm
Contact plating: Gold 6 micro-inches min.In contact area.
4. Wave solder tip temperature: 265℃ Max, 5 Sec Max
5. UL Certification: File Number E484635

LPJ0011FBNL 100Base-T RJ45 Connector with Magnetic For I/O Date
