FA0185 Lan Transformer 48 Positions Dual Ports Surface Mounting 1000Mbps

Name: FA0185 Lan Transformer 48 Positions Dual Ports Surface Mounting 1000Mbps
Brand: LINK-PP
Price: 0.06 USD

FA0185 Lan Transformer 48 Positions Dual Ports Surface Mounting 1000Mbps Manufactures

Place of Origin : Guangdong,China

Brand Name : LINK-PP

Certification : UL,RoHS,Reach,ISO

Model Number : FA0185

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Packaging Details : T&R

Delivery Time : Stock

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

PN# : FA0185

Made In China : SM-LP5014ANLE

Interface : Gigabyte

Samples : Free

Archivi Disponibili : PDF/3D/ISG/Stp/Step/Datasheet

Contact Now

FA0185 Lan Transformer 48 Positions Dual Ports Surface Mounting 1000Mbps

Electrical Specification @25℃
1.Insertion Loss:
1-100MHz:-1.4dB Max
2.Return Loss(dB Min):
1-30MHz:-16 40MHz:-14.4
50MHz:-13.1 60-80MHz:-12
100MHz:-10
3.Crosstalk(dB Min):
30MHz:-43.5 60MHz:-37.5
100MHz:-33
4.DCMR(dB Min):
30MHz:-45 60MHz:-40
100MHz:-35
5.Hipot: 1500Vrms Min
6.Operating Temperature: -40℃～+85℃.

FA0185 Lan Transformer 48 Positions Dual Ports Surface Mounting 1000Mbps
