LPJ16264A28NL Cross 5-6605578-1 RJ45 Transformer 1 x 10/100 Mbit Ethernet

Name: LPJ16264A28NL Cross 566055781 RJ45 Transformer 1 x 10100 Mbit Ethernet
Brand: LINK-PP
Price: 1 USD

LPJ16264A28NL Cross 5-6605578-1 RJ45 Transformer 1 x 10/100 Mbit Ethernet Manufactures

Brand Name : LINK-PP

Model Number : LPJ16264A28NL

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4600K.PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Specification : 5-6605578-1

Part No : LPJ16264A28NL

Mounting : Thru-hole

Ethernet : 1x10/100Mbps

Indicator : Resistor LED

Samples : Available Free

Contact Now

LPJ16264A28NL Cross 5-6605578-1 RJ45 Transformer 1 x 10/100 Mbit Ethernet

Specification	Part No	Manufacturer	Description
Cross 5-6605578-1	LPJ16264A28NL	LINK-PP	1xrj45,10/100,R/A,LED Resistor,Shield,tab-up

Series	Connector Type	Applications	Mounting Type
Connectors, Interconnects	LINK-PP Rj45	10/100Base-T	Thru-hole

Orientation	Termination	LED Color	Shielding
90° Angle (Right)	Solder	G/Y	Shielded ,EMI

Electrical Specifications @25℃
1.Turns Ratio(±2%):
TX=1CT:1CT RX=1CT:1CT
2.Primary Inductance(1-2, 5-6): 350uH Min
@100KHz,0.1Vrms,8mA DC bias
3.Insertion Loss:
0.5-100MHz: -1.1dB Max
4.Return Loss(dB Min):
0.5-30MHz:-18;
30.1-60MHz:-[18-20LOG(f/30)]
60.1-80MHz:-12
5.Crosstalk(dB Min):
0.5-40MHz: -35
40.1-100MHz: -[33-20LOG(f/50)]
6.Common Mode Rejection Ratio:
0.5-100MHz: -30dB Min
7.Hipot Test: 1500Vrms
8.Operating Temperature: 0℃～70℃.

LPJ16264A28NL Cross 5-6605578-1 RJ45 Transformer 1 x 10/100 Mbit Ethernet

Product Tags:

rj45 with magnetics

rj45 magnetic jack

LPJ16264A28NL Cross 5-6605578-1 RJ45 Transformer 1 x 10/100 Mbit Ethernet Images
