Name: Magnetic 8P8C 100BaseT RJ45 With Transformer LPJ6014AHNL
Brand: LINK-PP
Price: 1 USD

Brand Name : LINK-PP

Model Number : LPJ6014AHNL

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4600K.PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Produts Name : 8P8C RJ45 Connector with Integrated Magnetics

Transformer : Built-in

Mounting Type : PCB THT

Apllication : 10/100 Base-TX

LED Color : Green Yellow

Connector Length : 25.25 mm / 0.99 inch

Connector Width : 16.15 mm / 0.64 inch

Connector Height : 13.45 mm / 0.53 inch

Contact Now

RJ45 Connector with 10/100 Base-T Integrated Magnetics

Part Number	Number of Positions/Contacts	Manufacturer	Operating Temperature
LPJ6014AHNL	8P8C	LINK-PP	0C~70C
Series	Hipot	Applications	Mounting Type
RJ45 Connector with Magnetics	1500Vrms MIN	10/100 Mbps	Thru-Hole

Orientation	Termination	LED Color	Shielding
90° Angle (Right)	Solder	Yellow/Green	Shielded, EMI-Finger
LPJ6014AHNL RJ45 Connector Datasheet: LPJ6014AHNL.pdf Advantages of RJ45 Connector with Integrated Magnetics RJ-45 connector integrated with Filter Size same as RJ-45 connector to save PCB board space Reduce EMI radiation, Improve EMI performance High performance for maximum EMI suppression. ISO9001, SGS, UL, CE, REACH Embedded mini PCI express Cellular modem from SierraWireless Reduce EMI radiation, Improve EMI performance Certified on all major carrier networks, attractive for network interface cards (NICS) Single ports, Multi-port and Stackable configurations (Thru-hole/ SMT) Reduces the number of components to be placed on the board Frees up board space and offers signal protection Noise reduction in the system Improved reliability and optimal system performance The benefits of having shorter signal paths and the reliability gains from systems containing fewer components Helps manufacturers reach their goals of cost reduction

Details of RJ45 Magnetic Jack

Magnetic 8P8C 100Base-T RJ45 With Transformer LPJ6014AHNL
