E5TAB-1C0T02-L / E5TAB-1C0T12-L PCB Transformer SMT Jack Rj45 LPJ19201BGNL

Name: E5TAB1C0T02L E5TAB1C0T12L PCB Transformer SMT Jack Rj45 LPJ19201BGNL
Brand: LINK-PP
Price: 1 USD

E5TAB-1C0T02-L / E5TAB-1C0T12-L PCB Transformer SMT Jack Rj45 LPJ19201BGNL Manufactures

Brand Name : LINK-PP

Model Number : GE5TAB-XX0TXX

Certification : ISO9001,SGS,UL,CE,REACH

Place of Origin : GuangDong, China

MOQ : 600 PCS

Price : Supportive&Discount

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3000000/Month

Delivery Time : Stock

Packaging Details : 150PCS/Reel,6Reels/Carton,900PCS/Carton=35.5*35.5*35cm,Weight10KG

Part Number : LPJ19201BGNL

Cross : E5TAB-1COT02-L / E5TAB-1COT12-L

Ethernet : 10/100 Fast

Samples : Available& Free

Contact Now

E5TAB-1C0T02-L / E5TAB-1C0T12-L PCB Transformer SMT Jack Rj45 LPJ19201BGNL

LINK-PP Rj45 LPJ19201BGNL
Cross Specification GE5T3013-LC / GE5TAB-XX0TXX
E5TAB-1C0T02-L / E5TAB-1C0T12-L
SMT RJ45 Jack
Rj45 10/100 Base-T Transformer Jack With Impedance Resistor/High Voltage Capacitor
High performance for maximum EMI suppression.
LAN interface suitable for 100Base-TX for Communication Controllers
Designed for network interface card application and Network Adapter
Original materials are RoHS and UL94-V0 compliant
ISO9001,SGS,UL,CE,REACH

1.Turns Ratio(±2%):
TX=1CT:1CT

RX=1CT:1CT
2.OCL: 350uH Min
@100KHz,100mV,8mA bias current
3.Insertion Loss(dB Max):
1-80MHz:-1.0 100MHz:-1.2
4.Return Loss(dB Min @100Ω):
1-60MHz:-14 60-100MHz:-10
5.Crosstalk: 1-80MHz:-35dB Min
6.IR Reflow peak temperature: 260 degc.
7.Isolation Voltage: 1500Vrms Min
8.Operating Temperature: 0℃～70℃.

E5TAB-1C0T02-L / E5TAB-1C0T12-L PCB Transformer SMT Jack Rj45 LPJ19201BGNL
