RJ45 With Integrated Magnetics Pin-in-Paste JXR1-0001NL PulseJack 10/100BT
| JXR1-0001NL PulseJack |
| Trader Part Number | JXR1-0001NL | | Price Break | Unit Price | Extended Price | | 1-5 | A | - | | 10-50 | B | - | | 100-500 | C-1 | - | | 1,000-2,500 | Supportive | - | | 5,000 | Dynamic | Dynamic | | 10,000 | Dynamic | Dynamic | | 50,000 | Negotiable | Negotiable | | 100,000 | Negotiable | Negotiable | | 500,000 | Negotiable | Negotiable | |
| Made in China | SM-LPJ6011CNL |
| Manufacturer | LINK-PP China |
| Description | Rj-45 Integrated Transformers |
| Documents Available | PDF/3D/Step/IGS/Price/Cross |
| Quantity Available | 2,000 PCS or 4 weeks |
JXR1-0001NL Electrical Specifications
1.TR:(100KHz,0.1V);
TX=1CT:1CT ±3% RX=1CT:1CT ±3%P2.OCL:(100KHz,100mV,8mA,DC Bias)
PINS:(P1,P2),(P7,P8)=350uH MIN
3.HIPOT:
PINS(P1,P3,P2)TO (J1,J2)=1500VAC FOR 60 SECONDS
PINS(P7,P6,P8)TO (J3,J6)=1500VAC FOR 60 SECONDS
4.INSERTION LOSS:
-1.0dB MAX @ 0.3MHz TO 100MHz
5.RETURN LOSS:
-20dB MIN @ 1MHz TO 10MHz
-16dB MIN @ 10MHz TO 30MHz
-12dB MIN @ 30MHz TO 60MHz
-10dB MIN @ 60MHz TO 100MHz
6.CROSS TALK:
-40dB MIN @ 1MHz TO 30MHz
-35dB MIN @ 30MHz TO 60MHz
-30dB MIN @ 60MHz TO 100MHz
7.COMMON TO COMMON MODE REJECTION:
-30dB MIN @ 1MHz TO 50MHz
-20dB MIN @ 50MHz TO 150MHz
8.OPERATING TEMPERATURE: -40℃～+85℃.
NOTES:
1.Designed to support application,such as SOHO(ADSL
modems),LAN-on-Motherboard(LOM),hub and Switches.
2.Meets IEEE 802.3 specification
3.Connector Materials:
Housing: Thermoplastic PBT+30%G.F UL94V-0
Contact: Phosphor Bonze C5210R-EH Thickness=0.35mm
Pins: Brass C2680R-H Thickness=0.35mm
Shield: SUS 201-1/2H Thickness=0.2mm
Contact plating: Gold 6 micro-inches min.In contact area.
4.Wave solder tip temperature: 265℃ Max
Wave solder tip temperature time: 5 Sec Max
