V890-1AX1-A1 Vertical RJ45 Socket , LPJD0834BDNL 1x10/100/1000Mbps

Name: V8901AX1A1 Vertical RJ45 Socket LPJD0834BDNL 1x101001000Mbps
Brand: LINK-PP
Price: 0.09 USD

V890-1AX1-A1 Vertical RJ45 Socket , LPJD0834BDNL 1x10/100/1000Mbps Manufactures

Brand Name : LINK-PP

Model Number : V890-1AX1-A1

Certification : UL,ROHS,Reach,ISO

Place of Origin : GuangDong, China

MOQ : 50/500/1000/25K

Price : $0.09-$1.85

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3000000/Month

Delivery Time : Stock

Packaging Details : 40PCS/Tray,16Trays=640PCS=37*30*30CM=7KG/Carton

part Number : V890-1AX1-A1

Specification : LPJD0834BDNL

Part No : LPJD0834BDNL

Apllication : 1x10/100/1000Mbps

Mounting : Vertical 180 Degree

Samples : Available

Contact Now

V890-1AX1-A1 Vertical RJ45 Socket , LPJD0834BDNL 1x10/100/1000Mbps

Specification	PN	Manufacturer	Description
V890-1AX1-A1	LPJD0834BDNL	LINK-PP	Vertical Rj45 Jack With Integrated Magnetic
Series	Connector Type	Applications	Mounting Type
Connectors, Interconnects	LINK-PP Female Rj45	1000Mbps	Thru-Hole
Orientation	Termination	LED Color	Shielding
180°(Vertical)	Solder	Y&G	Shielded
Vertical Rj45 With Magnetics / Vertical Rj45 Socket LPJD0834BDNL Electronics Specifications @25℃ 1.TURNS RATIO(%%P3%): TX=1CT:1CT RX=1CT:1CT 2.OCL(100KHz,0.1V,8mA): 350uH MIN 3.HIPOT(Isolation Voltage): 1500Vrms 4.INSERTION LOSS: -1.1dB MAX @ 1MHz TO 100MHz 5.RETURN LOSS(100 OHMS %%P15%): -18dB MIN @ 1MHz TO 40MHz -14dB MIN @ 60MHz -12dB MIN @ 80MHz -10dB MIN @ 100MHz 6.CROSS TALK: -40dB MIN @ 1MHz TO 30MHz -30dB MIN @ 30MHz TO 60MHz 7.CM TO CM REJ: -20dB MIN @ 1MHz TO 100MHz 8.OPERATING TEMPERATURE RANGE:0℃～+70℃.
