Belfuse SI-50170-F Magnetic RJ45 Jack LPJ1014AWNL Tab-Up 10/100M With LEDs

  • 1
  • 2
  • 3

Brand Name : LINK-PP

Model Number : SI-50170-F

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4600K.PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

part Number : SI-50170-F

Made IN China : SM-LPJ1014AWNL

Cross&Datasheet : LPJ1014AWNL

Apllication : 10/100BT

Original Munafactuer : LINK-PP

Samples : Available

Contact Now

Belfuse SI-50170-F Magnetic RJ45 Jack LPJ1014AWNL Tab-Up 10/100M With LEDs

Part Number
Made In China
Manufacturer
Description
SI-50170-F
SM-LPJ1014AWNL
LINK-PP
Belfuse SI-50170-F Magnetic RJ45 Jack LPJ1014AWNL Tab-Up 10/100M With LEDs
Series
Connector Type
Applications
Mounting Type
Connectors, Interconnects
LINK-PP Female Rj45
10/100
Thru-Hole(SMT for Single Port)
Orientation
Termination
LED Color
Shielding
90° Angle (Right)
Solder
With Or Without
shielded,EMI-Finger
SI-50170-F Specifications:

TEST NOTES(25±5℃)
1.TR:(100KHZ,100mV);
TX=1CT:1CT ±3%

RX=1CT:1CT ±3%

2.LX:(100KHZ,100mV,8mA,DC Bias)
PINS:(P1,P3),(P4,P6)=350uH MIN
3.HIPOT:
PINS(P1,P2,P3)TO (J1,J2)=1500V
PINS(P4,P5,P6)TO (J3,J6)=1500V
4.INSERTION LOSS:
-1.0dB MAX @ 1.0MHz TO 65MHz
5.RETURN LOSS:
-20dB MIN @ 1MHz TO 10MHz
-16dB MIN @ 10MHz TO 30MHz
-12dB MIN @ 30MHz TO 60MHz
-10dB MIN @ 60MHz TO 100MHz
6.CROSS TALK:
-40dB MIN @ 1MHz TO 30MHz
-35dB MIN @ 30MHz TO 60MHz
-30dB MIN @ 60MHz TO 100MHz
7.COMMON TO COMMON MODE REJECTION:
-30dB MIN @1MHz TO 50MHz
-20dB MIN @50MHz TO 150MHz
8.Operating Temperature: 0℃～70℃.
SI-60085-F
ARJ11G-MBSC-MU2
857913020
85793-1007
SI-60088-F
ARJ11G-MBSD-LU2
857914020
85793-1007
SI-60089-F
ARJ11G-MBSE-MU2
857931001
85793-1007
SI-60090-F
ARJ12A-MASD-A-B-EMU2
857931001
85793-1010
SI-60091-F
ARJ12A-MASD-A-B-FMU2
857931003
85793-1012
SI-60092-F
ARJ12A-MCSD-MU2
857931006
85793-1013
SI-60093-F
ARJ14A-MSA-MU2
857931007
85793-1014
SI-60095-F
ARJ14A-MSB-MU2
857931007
85793-1020
SI-60096-F
ARJ14A-MSC-MU2
857931007
85793-1020
SI-60097-F
ARJ14A-MSD-A-B-ΔMU2
857931010
85793-1020
SI-60098-F
ARJ14A-MSD-MU2
857931012
85793-3006
SI-60101-F
ARJ14A-MBSD-A-B-EMU2
857931013
85793-3007
SI-60102-F
ARJ21A-MCSA-LU2
857931014
95540-2881
SI-60103-F
ARJ21A-MCSB-MU2
857931020
95540-7886
SI-60104-F
ARJ21A-MCSC-MU2
857931020
95622-3882
SI-60105-F
ARJ21A-MCSD-MU2
857931020
95622-3981
SI-60106-F
ARJ21A-MBSD-A-B-EMU2
857933006
438146621
SI-60107-F
ARJ-101D
857933007
432024101
