7499011212A Magnetic Jack 8P8C LAN-Übertrager WE-RJ45 LAN 10/100BaseT

Product Categories

LINK-PP INT'L TECHNOLOGY CO., LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 7499011212A Magnetic Jack 8P8C LANÜbertrager WERJ45 LAN 10100BaseT
Brand: LINK-PP
Price: 1 USD

Brand Name : LINK-PP

Model Number : 7499011212A

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4600K.PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

part Number : 7499011212A

Made In China : SM-LPJ0011ABNL

Category : Transformer Rj45

Apllication : 10/100BT

Original Munafactuer : LINK-PP

Mail Customer : Ti, Intel, Cisco, Samsung, Fluke,Jabil,Flextronics

Contact Now

Part Number	Made In China	Manufacturer	Description
7499011212A	SM-LPJ0011ABNL	LINK-PP	SIN Rj45 10/100BT
Series	Connector Type	Applications	Mounting Type
Connectors, Interconnects	LINK-PP Female Rj45	10/100	Thru-Hole(SMT Optional)
Orientation	Termination	LED Color	Shielding
90° Angle (Right)	Solder	Optional	(Un)Shielded,EMI-Finger
ELECTRICAL SPECFICATIONS: @25℃ 1.Turn Ratio(±2%): TX=1CT:1 RX=1CT:1 2.Inductance OCL: 350uH MIN @ 100KHz 0.1V 8mA DC Bias 3.Insertion Loss: -1.0dB MAX @ 1.0-100MHz 4.Return Loss: -18dB MIN @ 1-30MHz -15dB MIN @ 30-60MHz -12dB MIN @ 60-80MHz -10dB MIN @ 80-100MHz 5.Cross talk: -40dB MIN @ 30MHz -35dB MIN @ 60MHz -30dB MIN @ 100MHz 6.Common Mode Rejection: -40dB MIN @ 30MHz -35dB MIN @ 60MHz -30dB MIN @ 100MHz 7.Hipot: 1500Vrms 8.LED Lamp: Wave Length:GREEN/YELLOW:570nm/590nm Forward Voltage(Vf): 1.8V-2.4V (Test Condition: 20mA) 9.Operating Temperature Range:0℃ TO 70℃

7499011212A Magnetic Jack 8P8C LAN-Übertrager WE-RJ45 LAN 10/100BaseT
