7490100161A 10/100base-Tx Magnetic Transformer 1500Vrms with SMT Mounting

Name: 7490100161A 10100baseTx Magnetic Transformer 1500Vrms with SMT Mounting
Brand: LINK-PP
Price: 0.06 USD

7490100161A 10/100base-Tx Magnetic Transformer 1500Vrms with SMT Mounting Manufactures

Brand Name : LINK-PP

Model Number : 7490100161A

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Delivery Time : Stock

Packaging Details : T&R

Specifications : 7490100161A

Equivalent : LP1198NL

Turn Ratio : 1:1

Mounting : SMT

Ethernet : 1x10/100Base-Tx

Dielectric : 1500Vrms

File : PDF/3D/ISG/Stp/Step/Datasheet

Contact Now

7490100161A 10/100base-Tx Magnetic Transformer 1500Vrms 1min

Equivalent to 7490100161A
l IEEE 802.3 Ethernet Compatible,10/100 Base-TX
Surface Mountable(Miniature size)
10/100 Base-T Transformer Modules
LP1188NL Compatible of 7490100161A Equivalent Specifications
operating temperature:-40°C - +125°C
Hipot test: 1500Vrms 1min.
Compliant with IEEE 802.3u for 10/100Base-TX-Applications
Auto MDIX capable

Single Port, 10/100 BASE-T Ethernet Transformer Modules, SMD,Rohs
LINK-PP Part Number	LP1198NL
WE Part Number	7490100161A
Speed	10/100BASE-T
Number of Ports	SINGLE
Application - LAN	ETHERNET (NON PoE)
Package	SMD
Temperature	- 40 TO + 85
AutomDX	YES
Comment	SAME AS NL VERSION
Construction	OPEN FRAME
Cores Per Port	4
Package Height (mm)	5.65
Package Length (mm)	12.8
Package Width (mm)	6.90
Turns Ratio RX	1CT:1CT
Turns Ratio TX	1CT:1CT

Why Choose Us

World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers

100% Guarantee Qualtiy

•Manufactured Under Strict Controls.

•100% Tested (Not Just Batch Tested)

•LINK-PP Is OEM Of TE (Tyco) For 9 Years

•Successful Customer: Texas Instruments Samsung Cisco Siemens And Intel…

•LINK-PP Is The Preferred Supplier Of TI (Texas Instruments)

•Quality Guarantee:6 Years

7490100161A 10/100base-Tx Magnetic Transformer 1500Vrms with SMT Mounting

Competitive Price And Service

•More Competitive Price Than Pulse Tyco Halo And Amphenol

•Delivery Time:2-3 Weeks After Orders

•Free Samples Are Available

•Provide New Design For Customer Requirements

•90% Off Shipping Cost By DHL UPS DEDEX Or TNT

Professional Certification

•ISO 9001:2008

•UL Certification

•Reach Cetitifaction

•RoHS Compliance

•Active Environmental Policy

LINK-PP Corporate Policy

•The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction

Through Continuous Improvements In Quality, Delivery And Service

• LINK-PP Is Committed To And Expects Quality Performance From Every Employee

• The Company Standard Is Defect-Free Products And Services

7490100161A 10/100base-Tx Magnetic Transformer 1500Vrms 1min
