Name: 40SS1064ALF 10100BASETX Quad Port Magnetic Transformer LP44008NL
Brand: LINK-PP
Price: 0.06 USD

Brand Name : LINK-PP

Model Number : 40SS1064ALF

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Delivery Time : Stock

Packaging Details : T&R

Specifications : 40SS1064ALF

P/N : LP44008NL

Measure : 28.58mm X 16.00mm X 6.60mm

Mounting : SMT

Ethernet : 4 Port 10/100Mbps

Archivi Disponibili : PDF/3D/ISG/Stp/Step/Datasheet

Contact Now

40SS1064ALF 10/100BASE-TX Quad Port Magnetic Transformer LP44008NL

Audio Transformers / Signal Transformers 10/100Base-TX SMD 4Port
For Use with Transceivers Requiring 1:1 Transmit and Receive Turns Ratios

10/100BASE-TX QUAD PORT TRANSFORMER MODULES For Use with Transceivers Requiring 1:1 Transmit and Receive Turns Ratios

Mfr Package Description	ROHS COMPLIANT
REACH Compliant	Yes
EU RoHS Compliant	Yes
Status	Alternated by LINK-PP
Transformer Type	DATACOM TRANSFORMER
Application	10/100 BASE-TX
Isolation Voltage	1500.0 V
Manufacturer Series	LP44008NL
Mounting Feature	SURFACE MOUNT
Number of Functions	4
Operating Temperature-Min	0.0 Cel
Operating Temperature-Max	70.0 Cel
Packing Method	TAPE & REEL; TUBE
Physical Dimension	28.58mm X 16.00mm X 6.60mm
Primary Inductance	350.0 µH
Terminal Finish	MATTE TIN
Turns Ratio (Np:Ns)	1:1; 1:1; 1:1; 1:1
Height	5.84 mm
Length	28.58 mm
Width	16.26 mm
Additional Feature	HEIGHT AND BREADTH DIMENSIONS INCLUDE TERMINALS ALSO

40SS1064ALF 10/100BASE-TX Quad Port Magnetic Transformer LP44008NL
