Name: 24HSS10412 Gigabit Ethernet Transformer Schematic With 1000 BaseTX LP5004NL
Brand: LINK-PP
Price: 0.06 USD

Brand Name : LINK-PP

Model Number : 24HSS1041-2

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Delivery Time : Stock

Packaging Details : T&R

Part Number : 24HSS1041-2

Speed : 1000 BASE-T

Number of Ports : SINGLE

Application : Lan Ethernet

Package : SMD

PIN number : 24

Temperature : 0℃ TO 70℃

Cores Per Port : 8

Contact Now

24HSS1041-2 Gigabit Ethernet Transformer Schematic With 1000 Base-TX LP5004NL

Detailed Information:

1000 Base -T Magnetics Transformer Modules SMD, Rohs
LINK-PP Part Number	LP5004NL
Bothhand Part Number	24HSS1041-2
Speed	1000BASE-T
Number of Ports	SINGLE
Application - LAN	ETHERNET (NoN PoE)
Package	SMD
Temperature	0℃ TO 70℃
AutomDX	YES
Comment	SAME AS NL VERSION
Configuration RX	T,C,S
Configuration TX	T,C,S
Construction	OPEN FRAME
Cores Per Port	8
Number of Ports	SINGLE
Package Height (Inches)	0.246
Package Height (mm)	6.25
Package Length (Inches)	0.715
Package Length (mm)	18.15
Package Width (Inches)	0.630
Package Width (mm)	16.00
Turns Ratio RX	1CT:1CT
Turns Ratio TX	1CT:1CT

24HSS1041-2 Gigabit Ethernet Transformer Schematic With 1000 Base-TX LP5004NL
