HFJ11-E1G01E-L12RL 1000 Base-T RJ45 Filter Connector Module LPJG4813GENL

Name: HFJ11E1G01EL12RL 1000 BaseT RJ45 Filter Connector Module LPJG4813GENL
Brand: LINK-PP
Price: 1 USD

HFJ11-E1G01E-L12RL 1000 Base-T RJ45 Filter Connector Module LPJG4813GENL Manufactures

Brand Name : LINK-PP

Model Number : HFJ11-E1G01E-L12RL

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : OEM Price

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 6000K/month

Delivery Time : Stock

Packaging Details : Tray Package: Carton size 32*30*31cm , G.W/carton 8.5kg , Qty/carton 1200pcs , SPQ 50pcs

Spec : LPJG4813GENL

Port : 1x1 Female Rj45

Magnetics : 1000 Base-T

LED : Green/Yellow Leds

Mounting : Right Angle

Cross Ref : HFJ11-E1G01E-L12RL

File : PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters

Contact Now

HFJ11-E1G01E-L12RL 1000 Base-T RJ45 Filter Connector Module Stock LPJG4813GENL

Package	Bulk
Part Status	Active
Connector Type	RJ45
Applications	1000 Base-T, AutoMDIX
Mounting Type	Through Hole
Orientation	90℃ Angle (Right)
Termination	Solder
Height Above Board	0.526" (13.36mm)
LED Color	Green/Yellow
Number of Cores per Jack	8
Shielding	Shielded, EMI Finger
Features	Board Guide
Tab Direction	Down
Contact Material	Phosphor Brass
Contact Finish	Gold
Operating Temperature	-40℃ ~ 85℃
Contact Finish Thickness	6.00uin (0.152um)
Shield Material	Brass
Housing Material	Thermoplastic
Number of Ports	1
Number of Rows	1

HFJ11-E1G01E-L12RL 1000 Base-T RJ45 Filter Connector Module LPJG4813GENL

Why Choose Us

World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers

100% Guarantee Qualtiy

•Manufactured Under Strict Controls.

•100% Tested (Not Just Batch Tested)

•LINK-PP Is OEM Of TE (Tyco) For 9 Years

•Successful Customer: Texas Instruments Samsung Cisco Siemens And Intel…

•LINK-PP Is The Preferred Supplier Of TI (Texas Instruments)

•Quality Guarantee:6 Years

HFJ11-E1G01E-L12RL 1000 Base-T RJ45 Filter Connector Module LPJG4813GENL

•Free Samples. •Delivery Time 1-2 Weeks.

LINK-PP Electronic SFPRJ45 Connector and LAN Transformer 10+ years of Manufacturing Experience.

Factory

•We have over 1000 workers.

•The area of ZhuSun is 60,000 square meters.

•Yueqing ZhuSun Electronics Co.,Ltd have owns 3 factory in sichuan,hubei,Zhejiang.

Quality

•Lean production management.

•100% Tested (Not Just Batch Tested).

•Quality Guarantee:5 Years.

Certification

•ISO 9001:2008,

•ROHS CE FCC Compliance

•Active Environmental Policy.

Have R&D dept

•OEM Service Offered,Design Service Offered.

•Engineer Can Design Products As You Need,Developer Tooling As Customer Require.

Price And Service

•Than PULSE TE HALO BEL Wurth Amphenol MOLXE BOTHHAND ABRACON FOXCONN And HANRUN More Competitive Price And Delivery.

Product Tags:

HFJ11-E1G01E-L12RL RJ45 Filter Connector

LPJG4813GENL RJ45 Filter Connector

HFJ11-E1G01E-L12RL 1000 Base-T RJ45 Filter Connector Module LPJG4813GENL Images
