1x10M 10Base-T Magnetic Transformers Isolation Module 23Z467SMFNLT

Name: 1x10M 10BaseT Magnetic Transformers Isolation Module 23Z467SMFNLT
Brand: LINK-PP
Price: 0.06 USD

Brand Name : LINK-PP

Model Number : 23Z467SMFNLT

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Delivery Time : Stock

Packaging Details : T&R

Specifications : 23Z467SMFNLT

Ethernet : 1x10M

Mounting : SMD

Measure : 5.59x11.43x9.144mm

Application : ETHERNET (NON PoE)

PIN number : 16

Temperature : 0 TO + 70℃

Archivi Disponibili : PDF/3D/ISG/Stp/Step/Datasheet

Contact Now

23Z467SMFNLT Single Port Magnetic Transformers 10Base-T Isolation Module

1. Coil Number: Autotransformer
2. Isolation Voltage:1500Vrms
3.Type:SMT 23Z467SMFNLT
4. Coil Structure: Toroidal

Part Status	Active
Transformer Type	Isolation and Data Interface (Encapsulated)
Inductance	140µH
ET (Volt-Time)	-
Turns Ratio - Primary:Secondary	1CT:2CT Transmitter, 1CT:1CT Receiver
Mounting Type	Surface Mount
Size / Dimension	0.450" L x 0.265" W (11.43mm x 6.73mm)
Height - Seated (Max)	0.215" (5.46mm)
Operating Temperature	0°C ~ 70°C
Weight	0.03 oz (0.85 g)

1x10M 10Base-T Magnetic Transformers Isolation Module 23Z467SMFNLT

Applications:

Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem

Competitive Advantage:

1100 staff,

100% test

Flexible delivery time

Product Tags:

10Base-T Magnetic Transformers Isolation Module

1x10M Magnetic Transformers Isolation Module

23Z467SMFNLT
