RM4-11NADV1F 2x4 Ports Stackable Jack LPJ47408AHNL 10 / 100Base-T W / LEDs

Product Categories
LINK-PP INT'L TECHNOLOGY CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

RM4-11NADV1F 2x4 Ports Stackable Jack LPJ47408AHNL 10 / 100Base-T W / LEDs

Brand Name : LINK-PP

Model Number : RM4-11NADV1F

Certification : UL,RoHS,Reach,ISO

Place of Origin : GuangDong, China

MOQ : 50/500/1000/60K

Price : $0.11-$24

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 180K/Month

Delivery Time : Stock

Packaging Details : Tray

part Number : RM4-11NADV1F

Specification : LPJ47408AHNL

Cross&Datasheet : LPJ47408AHNL

Apllication : 10/100 or 1000Base-T(x)

Original Munafactuer : LINK-PP

Project Application : NETWORK INTERFACE CARD

Contact Now

RM4-11NADV1F 2x4 Ports Stackable Jack LPJ47408AHNL 10 / 100Base-T W / LEDs

Competitor Cross Reference

Part Number

Manufacturer

Part Number

 Manufacturer Description

RM4-11NADV1F

LPJ47408AHNL

 LINK-PP

RM4-11NADV1F 2x4 Ports Stackable Jack LPJ47408AHNL 10 / 100Base-T W / LEDs
Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Female Rj45

10/100

or 1000 Mbps

 Thru-Hole(SMT for Single Port)
Orientation Termination LED Color Shielding

90° Angle (Right) or

180°(Vertical)

 Solder With Or Without (Un)Shielded,EMI-Finger(With Or Wi)

Features

  • RJ-45 connector integrated with Filter
  • Size same as RJ-45 connector to save PCB board space
  • Reduce EMI radiation, Improve EMI performance
  • High performance for maximum EMI suppression.
  • ISO9001,SGS,UL,CE,REACH
  • Embedded mini PCI express Cellular modemfrom SierraWireless
  • Reduce EMI radiation, Improve EMI performance
  • Certified on all major carrier networks,attractive for network interface cards(NICS)Single port,
  • Multi-port and Stackable configurations (Thru-hole/ SMT)

  • Reduces the number of components to be placed on the board

  • Frees up board space and offers signal protection

  • Noise reduction in the system

  • Improved reliability and optimal system performance

  • Benefits of having shorter signal paths and the reliability gains from systems containing fewer components

  • Helps manufacturers reach their goals of cost reduction
