RJS-1X08T089S2 Magnetic Ethernet RJ45 Jack LPJ16206AFNL 10 / 100Base-T Tab-Up

Brand Name : LINK-PP

Model Number : RJS-1X08T089S2

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000

Price : Supportive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4600K.PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

part Number : RJS-1X08T089S2

Specification : LPJ16206AFNL

Cross&Datasheet : LPJ16206AFNL

Apllication : 10/100 Base-T Rj45

Original Munafactuer : LINK-PP

Project Application : NETWORK INTERFACE CARD

Contact Now

RJS-1X08T089S2 Magnetic Ethernet RJ45 Jack LPJ16206AFNL 10 / 100Base-T Tab-Up

Competitor Cross Reference

Part Number

Manufacturer

Part Number

 Manufacturer Description

RJS-1X08T089S2

LPJ16206AFNL

 LINK-PP

RJS-1X08T089S2 Magnetic Ethernet RJ45 Jack LPJ16206AFNL 10 / 100Base-T Tab-Up

Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Rj45 100Mbps Thru-Hole
Orientation Termination LED Color Shielding
90° Angle (Right) Solder G/G Shielded,EMI-Finger

Features

  • RJ-45 connector integrated with Filter
  • Size same as RJ-45 connector to save PCB board space
  • Reduce EMI radiation, Improve EMI performance
  • High performance for maximum EMI suppression.
  • ISO9001,SGS,UL,CE,REACH
  • Embedded mini PCI express Cellular modemfrom SierraWireless
  • Reduce EMI radiation, Improve EMI performance
  • Certified on all major carrier networks,attractive for network interface cards(NICS)Single port,
  • Multi-port and Stackable configurations (Thru-hole/ SMT)

  • Reduces the number of components to be placed on the board

  • Frees up board space and offers signal protection

  • Noise reduction in the system

  • Improved reliability and optimal system performance

  • Benefits of having shorter signal paths and the reliability gains from systems containing fewer components

  • Helps manufacturers reach their goals of cost reduction

Related Part

LPJ16064A28NL LPJ16221AFNL LPJ16206A28NL LPJ15212CNL
LPJ16093CNL LPJ16222DNL LPJ16206A42NL LPJ15212AENL
LPJ16093DNL LPJ16249A28NL LPJ16206AFNL LPJ1514CNL
LPJ16112ADNL LPJ16249A28NL LPJ16207ADNL LPJ15125AENL
LPJ16112AFNL LPJ16249AZNL LPJ16208CYNL LPJ15125CNL
LPJ16112AZNL LPJ16249B28NL LPJ16208DNL LPJ15125AENL
LPJ16113CNL LPJ16249CNL LPJ16211BENL LPJ16117AENL
LPJ16113DNL LPJ16251A28NL LPJ16211CNL LPJ16117BENL
LPJ16115A28NL LPJ16251AZNL LPJ16211DNL LPJ16125AENL
LPJ16116A28NL LPJ16264A28NL LPJ16212ADNL LPJ16128DNL

RJS-1X08T089S2 Magnetic Ethernet RJ45 Jack LPJ16206AFNL 10 / 100Base-T Tab-Up

RJS-1X08T089S2 Magnetic Ethernet RJ45 Jack LPJ16206AFNL 10 / 100Base-T Tab-Up

Why Choose LINK-PP

Quality

World’s Leader supplier of Integrated RJ45 Connector and Discrete Magnetic Transformers.

Original materials suppliers are selected and appointed by Tyco Electronic ,and then put into production at the standard of Tyco Electronic .

  • Manufactured under strict controls.
  • ISO 9001:2008
  • UL Certification
  • Reach Cetitifaction
  • RoHS compliance
  • OEM Of TE(Tyco) For 9 Years
  • Active Environmental policy
  • Every module tested (not just batch tested)
Main Customers

Texas Instruments INTEL SAMSUNG FLUKE EKF HUAWEI IBM CISCO
FLEXTRONICS JABIL Foxconn CANON Arduino -- --- ---

LINK-PP RJ45 Designed for BeagleBone Black of Texas Instruments

LINK-PP is the preferred supplier of Texas Instruments ,Samsung, Cisco ,Siemens and INTEL.

Welcome to visit the Texas Instruments's websit: http://www.ti.com/tool/beaglebk#0 You will look at our logo "LINK-PP”on BeagleBone Board

LINK-PP ------------ Appointed Supplier And Supporter Of Embedded System for Ti
